This is a Repair Service of your existing EME Electric Motor Electronics, also known as Hybrid High Voltage Battery Inverter or DC to DC and DC to AC Converter. You will need to remove and send your module to us for repair using the shipping labels provided to you.

Programming will be required. Please note that your repaired EME will be shipped back to you in virgin state (just like new unit from the dealer). This means it will need to be programmed to your vehicle again.

The order will be processed during our regular business hours (Mon-Fri 8:30 – 5:00 EST). After processing your order, we will email shipping labels and shipping instructions. If you do not see shipping labels within 1 hour of submitting your order (during business hours) please first check your junk/spam folders. If you still do not see the labels, please contact us at 1-888-712-2525

Features:

Shipping notes: The EME is heavy, bulky and very expensive!!! Please make sure that it is properly protected.

Quick Turnaround: Your module will be tested, repaired, tested again, and sent back to you in the same day (unless otherwise noted).

Quality Tested: All EME modules undergo rigorous tests on our specialized custom-built CAN-bus driven test bed. All functions, DTCs, and software are checked and verified for proper operation.

Lifetime Limited Warranty: This module comes with our Lifetime Limited Warranty. Please see here for more information.

Reference Numbers

12369494405 | 12-36-9-494-405 | 12368679696 | 12368679697 | 12368688849 | 12368688850 | 12369494402 | 12369494403 | 12369494404

Common Failure Symptoms

Important Shipping & Programming Notice

Your repaired EME will be shipped back in a virgin (unprogrammed) state.
The EME must be programmed and coded to the vehicle before operation.

Primary Symptoms

No communication with EME
Low-voltage battery not charging

Key Fault Codes Related to EME Failure

Emergency Run Manager / Power Management

DTC 213901 – Power management: Reduction or shutdown of individual electrical consumer
DTC 21A003 – Emergency Run Manager: Request for torque reduction
DTC 21A11A – Emergency Run Manager: Request for deactivation of MSA with combustion engine
DTC 235410 – Emergency Run Manager: Request for idle speed increase from EME

Common Scan Tool Global Readout

(Observed when EME communication is lost)
Battery Management Electronics / SME

CAD405 – No message (OBD diagnosis, engine control, electrical – 0xJE4J), Receiver: SME, Transmitter: EME
CAD413 – No message (HV battery specification – 0x433), Receiver: SME, Transmitter: EME
CAD415 – No message (electronics disconnect switch, HV battery – 0x10B), Receiver: SME, Transmitter: EME
CAD416 – Signal (status of electric motor 1 – 0x10B) invalid, Transmitter: EME
CAD426 – No message (state of charge – 0x3E), Receiver: SME, Transmitter: EME
CAD428 – No message (subsystems control – 0x19E), Receiver: SME, Transmitter: DME/DDE

Voltage-Related SME Faults

21F02B – SME: Overvoltage (Terminal 30)
21F10D – SME: Undervoltage (Terminal 30)
21F10E – SME: Overvoltage (Terminal 30)
21F1F6 – HV battery switch contactors: Switch-off after a fault

Integration Level Check

Verify current I-Level of the vehicle.
If applicable:

Model F15 – Target I-Level: 17-03-5xx or earlier

DME (Digital Motor Electronics)

213A20 – Vehicle voltage too high

TCM / EGS (Transmission Control)

CF26A1 – Message group fault 1 (significant driving effect):
No message, Receiver: EGS (PT-CAN2), Transmitter: EME
CF26C1 – Message group fault 3 (no driving effect):
No message, Receiver: EGS (PT-CAN2), Transmitter: EME

DSC (Dynamic Stability Control)

48095D – Undervoltage at control unit
4809AB – Undervoltage in vehicle
4809DD – Undervoltage in vehicle

KLE / Charging System Faults

21E61E – KLE overvoltage
21E67B – HV charging socket cover: Hall sensor disconnection
21E689 – HV charging socket cover: Charging plug lock status implausible
21E69A – HV charging socket cover: Charging plug lock sensor short to ground

Charging Communication Errors

CE1410 – Missing message (charge status – 0x3E9), Receiver: LIM, Transmitter: EME
CE1501 – Signal (charging status – 0x09E) invalid, Transmitter: EME
CE1505 – Signal (traction status – 0x2E8) invalid, Transmitter: KOMBI
CE1506 – Signal (state of charge – 0x153) invalid, Transmitter: SME

EME Control Unit Details (EME2)

Part Number: 1905169 04
Hardware: 1236 / 9494404
Serial Number: 18B11710118
Coding Status: 0000

EME Functional Condition

The damaged EME:

Does not power on in the vehicle or on the bench
5 V reference supplies do not activate
No communication with any module
Peripheral modules report total communication failure with EME

Charging Control Communication Faults

S0769 – Communication cannot be established with Combined Charging Unit (KLE)
S0768 – CCU program interruption or communication failure with HV charging connection

LIM (Comfort Charging Electronics)

CE1410 – Missing message (state of charge – 0x3E9), Receiver: LIM, Transmitter: EME
CE1501 – Invalid signal (state of charge – 0x09E), Transmitter: EMR
CE1505 – Invalid signal (traction state – 0x2E8), Transmitter: KOMBI
CE1506 – Invalid signal (state of charge – 0x153), Transmitter: SME

How This Service Works

Step 1: Purchase our service online or over the phone.
Step 2: After processing your order, we will email you pre-paid shipping labels.
Step 3: Send us your old defective unit by dropping off the package to any UPS location or call UPS to schedule a pick- up.
Step 4: We will inspect and repair your old module.
Step 5: We will send you back the repaired module the same day (unless otherwise stated).
Step 6: You install the unit back into your vehicle.

For more detailed instructions, please see here.
